4. Speaker Adjustment
Room EQs
Whereas the ‘Tweeter Level’ raises or lowers a specic frequency range as a
whole, the ‘Room EQs’ work differently. They do not alter a whole frequency
band but alter in this band, from a certain point (6 kHz respectively 150 Hz in
this case) the frequencies are gradually being changed. The given dB values
occur at 30Hz and 15kHz. We show ve curves; however, the controls can be
changed continuously (see gure 8 & 9).
g. 8:
ROOM EQ >6 kHz
for the high frequencies
above 6 kHz
g. 9:
ROOM EQ <150 Hz
for the low frequencies
below 150 Hz
ANALOG INPUTS CONTROLS
ANALOG INPUTS CONTROLS
4.3
