Appendix E: Controller LED and I2C Connector Quick Reference ● 124
J12:
● Adaptec RAID 5085 Status LED Board Connector: Molex 10-89-7162 or equivalent
● Status LED Mating Cable Connector: Molex 22-55-2161 or equivalent
J14:
J12 Pin Number Signal Description
2 ~2kHz Square Wave Open collector transistor
1+3.3V
J14 Pin Number Signal Description
22-55-2161
Pin Number
1 +3.3V LED Anode 2
2 STATUS CN0, LANE 0 LED Cathode 1
3 +3.3V LED Anode 4
4 STATUS CN0, LANE 1 LED Cathode 3
5 +3.3V LED Anode 6
6 STATUS CN0, LANE 2 LED Cathode 5
7 +3.3V LED Anode 8
8 STATUS CN0, LANE 3 LED Cathode 7
9 +3.3V LED Anode 10
10 STATUS CN1, LANE 0 LED Cathode 9
11 +3.3V LED Anode 12
12 STATUS CN1, LANE 1 LED Cathode 11
13 +3.3V LED Anode 14
14 STATUS CN1, LANE 2 LED Cathode 13
15 +3.3V LED Anode 16
16 STATUS CN1, LANE 3 LED Cathode 15
