Adaptec 6405E - Adaptec RAID 5085 LED Connector Specification

Appendix E: Controller LED and I2C Connector Quick Reference ● 123
Adaptec RAID 5085 LED Connector Specification
● Adaptec RAID 5085 Activity LED Header Connector: Molex 10-89-7162 or equivalent
● Activity LED Header Mating Cable Connector: Molex 22-55-2161 or equivalent
J2:
● Adaptec RAID 5085 Aggregate Activity LED Board Connector: Molex 22-28-4023 or
equivalent
● Aggregate LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J1:
● Adaptec RAID 5085 External Alarm Connector: Molex 22-28-4023 or equivalent
● Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
2249100-R ASR-5085/512MB RoHS SGL
J2 Pin Number Signal Description
22-55-2161
Pin Number
1 +3.3V LED Anode 2
2 ACTIVITY CN0, LANE 0 LED Cathode 1
3 +3.3V LED Anode 4
4 ACTIVITY CN0, LANE 1 LED Cathode 3
5 +3.3V LED Anode 6
6 ACTIVITY CN0, LANE 2 LED Cathode 5
7 +3.3V LED Anode 8
8 ACTIVITY CN0, LANE 3 LED Cathode 7
9 +3.3V LED Anode 10
10 ACTIVITY CN1, LANE 0 LED Cathode 9
11 +3.3V LED Anode 12
12 ACTIVITY CN1, LANE 1 LED Cathode 11
13 +3.3V LED Anode 14
14 ACTIVITY CN1, LANE 2 LED Cathode 13
15 +3.3V LED Anode 16
16 ACTIVITY CN1, LANE 3 LED Cathode 15
J1 Pin Number Signal Description
2 ACTIVITY LED Cathode
1 +3.3V LED Anode
