Appendix E: Controller LED and I2C Connector Quick Reference ● 142
J12:
● Adaptec RAID 6805/6805Q I2C CN0 Board Connector: Molex 22-43-6030 or equivalent
● I2C Mating Cable Connector: Molex 22-43-3030 or equivalent
J4:
● Adaptec RAID 6805/6805Q I2C CN1 Board Connector: Molex 22-43-6030 or equivalent
● I2C Mating Cable Connector: Molex 22-43-3030 or equivalent
J5:
Adaptec RAID 6405E LED Connector Specification
● Adaptec RAID 6405E Activity LED Header Connector: Molex 22-43-6030 or equivalent
● Activity LED Header Mating Cable Connector: Molex 22-55-2161 or equivalent
J2:
J12 Pin Number Signal Description
2 ~2kHz Square Wave Open collector transistor
1+3.3V —
J4 Pin Number Signal
3 I2C Clock, CN0
2Ground
1I2C Data, CN0
J4 Pin Number Signal
3 I2C Clock, CN1
2 Ground
1I2C Data, CN1
2271700-R
ASR-6405E Kit
2270800-R
ASR-6405E SGL
J2 Pin Number Signal Description
22-55-2161
Pin Number
1 +3.3V LED Anode 2
2 ACTIVITY CN0, LANE 0 LED Cathode 1
3 +3.3V LED Anode 4
4 ACTIVITY CN0, LANE 1 LED Cathode 3
5 +3.3V LED Anode 6
6 ACTIVITY CN0, LANE 2 LED Cathode 5
7 +3.3V LED Anode 8
8 ACTIVITY CN0, LANE 3 LED Cathode 7
