Appendix E: Controller LED and I2C Connector Quick Reference ● 125
Adaptec RAID 5405/5405Z LED and I2C Connector
Specification
● Adaptec RAID 5405/5405Z Activity LED Header Connector: Molex 10-89-7162 or
equivalent
● Activity LED Header Mating Cable Connector: Molex 22-55-2161 or equivalent
J2:
● Adaptec RAID 5405/5405Z Aggregate Activity LED Board Connector: Molex 22-28-4023
or equivalent
● Aggregate LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J1:
● Adaptec RAID 5405/5405Z External Alarm Connector: Molex 22-28-4023 or equivalent
● Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
J12:
● Adaptec RAID 5405/5405Z I2C Board Connector: Molex 22-43-6030 or equivalent
● I2C Mating Cable Connector: Molex 22-43-3030 or equivalent
2258100-R ASR-5405 RoHS KIT
2258200-R
ASR-5405 RoHS Single
2266800-R ASR-5405Z RoHS Single
J2 Pin Number Signal Description
22-55-2161
Pin Number
1 +3.3V LED Anode 2
2 ACTIVITY CN0, LANE 0 LED Cathode 1
3 +3.3V LED Anode 4
4 ACTIVITY CN0, LANE 1 LED Cathode 3
5 +3.3V LED Anode 6
6 ACTIVITY CN0, LANE 2 LED Cathode 5
7 +3.3V LED Anode 8
8 ACTIVITY CN0, LANE 3 LED Cathode 7
J1 Pin Number Signal Description
2 ACTIVITY LED Cathode
1 +3.3V LED Anode
J12 Pin Number Signal Description
2 ~2kHz Square Wave Open collector transistor
1+3.3V —
