Appendix E: Controller LED and I2C Connector Quick Reference ● 129
● Adaptec RAID 5805/5805Q/5805Z/5805ZQ Aggregate Activity LED Board Connector:
Molex 22-28-4023 or equivalent
● Aggregate LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J1:
● Adaptec RAID 5805/5805Q/5805Z/5805ZQ External Alarm Connector: Molex 22-28-
4023 or equivalent
● Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
J12:
● Adaptec RAID 5805/5805Q/5805Z/5805ZQ I2C CN0 Board Connector: Molex 22-43-
6030 or equivalent
● I2C Mating Cable Connector: Molex 22-43-3030 or equivalent
J4:
● Adaptec RAID 5805/5805Q/5805Z/5805ZQ I2C CN1 Board Connector: Molex 22-43-
6030 or equivalent
● I2C Mating Cable Connector: Molex 22-43-3030 or equivalent
7 +3.3V LED Anode 8
8 ACTIVITY CN0, LANE 3 LED Cathode 7
9 +3.3V LED Anode 10
10 ACTIVITY CN1, LANE 0 LED Cathode 9
11 +3.3V LED Anode 12
12 ACTIVITY CN1, LANE 1 LED Cathode 11
13 +3.3V LED Anode 14
14 ACTIVITY CN1, LANE 2 LED Cathode 13
15 +3.3V LED Anode 16
16 ACTIVITY CN1, LANE 3 LED Cathode 15
J1 Pin Number Signal Description
2 ACTIVITY LED Cathode
1 +3.3V LED Anode
J12 Pin Number Signal Description
2 ~2kHz Square Wave Open collector transistor
1+3.3V —
J4 Pin Number Signal
3I2C Clock
2Ground
1I2C Data
J2 Pin Number Signal Description
22-55-2161
Pin Number
