Appendix E: Controller LED and I2C Connector Quick Reference ● 146
● Adaptec RAID 6805T/6805TQ Aggregate Activity LED Board Connector: Molex 22-28-
4023 or equivalent
● Aggregate LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J1:
● Adaptec RAID 6805T/6805TQ External Alarm Connector: Molex 22-28-4023 or
equivalent
● Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
J12:
● Adaptec RAID 6805T/6805TQ Aggregate Activity LED Board Connector: Molex 22-28-
4023 or equivalent
● Aggregate LED Mating Cable Connector: Molex 50-57-9002 or equivalent
J1:
● Adaptec RAID 6805T/6805TQ External Alarm Connector: Molex 22-28-4023 or
equivalent
● Alarm Mating Cable Connector: Molex 50-57-9002 or equivalent
J12:
14 ACTIVITY CN1, LANE 2 LED Cathode 13
15 +3.3V LED Anode 16
16 ACTIVITY CN1, LANE 3 LED Cathode 15
J1 Pin Number Signal Description
2 ACTIVITY LED Cathode
1 +3.3V LED Anode
J12 Pin Number Signal Description
2 ~2kHz Square Wave Open collector transistor
1+3.3V —
J1 Pin Number Signal Description
2 ACTIVITY LED Cathode
1 +3.3V LED Anode
J12 Pin Number Signal Description
2 ~2kHz Square Wave Open collector transistor
1+3.3V —
J2 Pin Number Signal Description
22-55-2161
Pin Number
