ALPHA Serial Clock Manual
18
Clock specifications
Clock Dimensions: 3.5” x 7.1” x 2.2” (34.3 cm x 18.0 cm x 5.6 cm)
Length x Height x Depth
Weight: 1.7 lbs. (0.78 kg) - clock
1.1 lbs. (0.50 kg) - AC adapter
Numeral Height 4” (10.2 cm)
Power: Utilizes 30 Watt transformer, UL Listed, CSA Certified, 120 VAC (transformer
input voltage range is 100-130 VAC)
Battery: Built-in battery backup to 15 days
Serial Interface: Surge Protected, RS485
Network Limitations: 32 drops
4000 feet at 9600 baud
Operating Temperature: 0°C - 49°C (32°F - 120°F)
Humidity: 0% - 95% Non-condensing
Factory Defaults: Slave Mode, 12-hour Mode, Bright Mode
