Figure 14: Wall-Mount, Conduit Drawing
NOTE: DO NOT blow out enclosures because metal shavings can damage the electronics.
11.30 in
287 mm
13.40 in
340 mm
FIBER OPTICS
TO CVM
(SEE NOTE 4)
TO
REGULATOR
OR CONTROL
DEVICE
COMM
TO CPU OR
NEXT ACE™
UPS
POWER
