2.3.4 Combo Box-Mount
Installation
Locate each ACE2 Combo Box unit as close as possible to each of the controllable elements
like the Regulator, the Generator, etc.
The Combo Box-Mount must be flush against a wall as in Figure 17 and Figure 18, or on
U-channels supporting all four corners of the enclosure. See Figure 19.
Figure 17: Combo Box-Mount, External View
