© ADB Airfield Solutions All Rights Reserved 29
Figure 22: Combo Box-Mount, Conduit Drawing
FIELD CABLES
20.36
517
20.36
517
COMM
AUX
FIBER
OPTICS
UPS
POWER
Dimensions
inch/mm
