ADB L-804 - Page 19

© ADB bvba All Rights Reserved 13
Figure 4: L-804 Base Installation
1. L-804 Light Fixture 3. L-867B Light Base 5. Hex Set Screw
2. Special Heavy Duty Base Plate 4. Concrete
1-L-804 Light Fixture
2-Special Heavy
Duty Base Plate
3-L-867B Light Base
4-Concrete
5-Hex Set
Screw
