SECTION III
SPECIFICATIONS and DIMENSIONS
A. SPECIFICATIONS (Gas and Steam Models)
NOTE: ADC reserves the right to make changes in specifications at any time, without notice or
obligation.
Gas*
Steam*
M AXIMUM C APACITY ( DRY WEIGHT ) 410 lbs. 186.4 kg
M
INIMUM C APACITY ( DRY WEIGHT ) 250 lbs. 113.65 kg
B
ASKET ( TUMBLER ) D IAMETER 68-3/4" 174.6 cm
B
ASKET ( TUMBLER ) D EPTH 66-3/8" 168.6 cm
B
ASKET ( TUMBLER ) V OLUME 143 cu. ft. 4.05 cu.m.
D
RIVE M OTOR 7-1/2 HP 5.6 kw
B
LOWER M OTOR ( GAS / STEAM )25 HP 18.7 kw
D
OOR O PENING 40" W IDE x 50" H IGH 101.6 cm x 127 cm
D
OOR S ILL H EIGHT - LEVEL 39-3/4" 101 cm
C
OMPRESSED A IR 80 PSI 5.63 kg/cu.m.
C
OMPRESSED A IR C ONNECTION 3/8" F.P.T. .953 cm
V
OLTAGE A VAILABLE 208-460v / 3ø / 3, 4w / 50/60 Hz
H
EAT I NPUT 1,600,000 btu/hr 403,200 kcal/hr
A
PPROX . W EIGHT ( UNCRATED ) 7,500 lbs. 3,409 kg
A
IRFLOW 9,200 cfm 261 cmm
Inlet Pipe Size 2" F.P.T.
5.08 cm
V
OLTAGE A VAILABLE 208-460v / 3ø / 3, 4w / 50/60 Hz
A
PPROX . W EIGHT ( UNCRATED ) 8,000 lbs. 3,636 kg
A
IRFLOW 12,000 cfm 340 cmm
S
TEAM C OMSUMPTION
B OILER HP
N
ORMAL L OAD
1,815 lbs/hr 825 kg/hr 55
O
PERATING S TEAM P RESSURE S TEAM S UPPLY S TEAM R ETURN
125 psi max 8.79 kg/sq cm 2" 5.08 cm 1-1/4" 3.18 cm
Shaded areas are stated in metric equivalents.
* Dryer mus t be provided with a clean, dry, regulated 80 PSI (+/- 10 psi) air supply (equivalent
volume - 11 cfh [0.3 cmh]).
