B. Electric Models Only
IMPORTANT: Figures shown are for non-reversing models ONLY. For reversing models
contact the factory.
IMPORTANT: The dryer must be connected to the electric supply shown on the data label that
is affixed to the back side of the upper/top control door. In the case of 208 VAC
or 230/240 VAC, the supply voltage must match the electric service
specifications of the data label exactly.
IMPORTANT: The wire size must be properly sized to handle the related current.
WARNING: 208 VAC and 230/240 VAC ARE NOT THE SAME. Any damage done to dryer
components due to improper voltage connections will automatically
VOID THE WARRANTY.
NOTE: ADC reserves the right to make changes in specifications at any time, without notice or
obligation.
APPROX. AMP DRAW
IMPORTANT: 3 phase figures shown are for a 3 wire service ONLY.
ADE-75 (Electric)
E LECTRICAL S ERVICE S PECIFICATIONS ( PER DRYER )
IMPORTANT: 208 VAC and 230/240 VAC ARE NOT THE SAME. When ordering, specify exact voltage.
NOTE
:
A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY.
B. Circuit breakers are thermal magnetic (industrial) type ONLY. For others, calculate/verify
correct breaker size according to appliance amp draw rating and type of breaker used.
C

Circuit breakers for 3Ø dryers must be 3-pole type.
APPLIED VOLTAGE/PHASE/FREQUENCY
KW 208 / 1ø/ 60Hz 240 / 1ø/ 60Hz 208 / 3ø/ 60Hz 240 / 3ø / 50/60Hz 380 / 3ø / 50Hz 416 / 3ø / 50Hz 460 /3ø / 60Hz
20 105 90 --- --- 33 --- ---
24 --- --- 72 63 --- 36 33
30 --- --- 88 77 --- 45 41
33 --- --- --- --- 53 --- ---
36 --- --- 104 92 --- 53 48
40 --- --- --- --- --- 59 ---
