20
2. ELECTRICAL SERVICE SPECIFICATIONS
A. Gas and Steam Models
IMPORTANT: Figures shown are for non-reversing models ONLY. For reversing models
contact the factory.
IMPORTANT: The dryer must be connected to the electric supply shown on the data label that
is affixed to the back side of the upper/top control door. In the case of 208
VAC or 230/240 VAC, the supply voltage must match the electric service
specifications of the data label exactly.
IMPORTANT: The wire size must be properly sized to handle the related current.
WARNING: 208 VAC and 230/240 VAC ARE NOT THE SAME. Any damage done to
dryer components due to improper voltage connections will automatically
VOID THE WARRANTY.
NOTE: ADC reserves the right to make changes in specifications at any time, without notice or
obligation.
ADG-75 (Gas)
ADS-75 (Steam)
ELECTRICAL SERVICE SPECIFICATIONS (PER DRYER)
IMPORTANT: 208 VAC
AND
230/240 VAC ARE NOT THE SAME. W
HEN
ORDERING
,
SPECIFY
EXACT
VOLTAGE
.
NOTE
:
A. Fuse ratings are dual-element, time-delay, current limiting, class RK1 or RK5 ONLY.
B. Circuit breakers are thermal magnetic (industrial) type ONLY. For others, calculate/verify correct
breaker size according to appliance amp draw rating and type of breaker used.
C. Circuit breakers for 3-phase (3ø) dryers must be 3-pole type.
SERVICE
VOLTAGE
PHASE
WIRE
SERVICE
APPROX.
AMP DRAW
MIMIMUM
WIRE SIZE*
FUSING
CIRCUIT
BREAKER
D
UAL
E
LEMENT
T
IME
D
ELAY
60 Hz 50 Hz
120 1ø 2 13 --- 10 20 20
208 1ø 2 8 --- 14 12 15
208 3ø 3/4 5 --- 14 8 15
240 3ø 3/4 5 5 14 8 15
240 1ø 2 7 7 14 12 15
380-400 3ø 3/4 --- 3 14 5 15
416 3ø 3/4 --- 3 14 5 15
460 3ø 3/4 3 --- 14 5 15
* AWG Stranded Wire ... for individual lenghts less than 100 feet.
