24 American Dryer Corp. 450325- 1
Remove Blower Housing / Replace Blower Motor
1. Discontinue electrical power to the dryer.
2. Disconnect the harness from motor, the hi-limit, exhaust probe and lint switch.
3. Remove the lint screen.
4. Remove the bottom toe panel.
5. Carefully remove the four Acorn nuts that hold the blower housing to the lint housing.
6. Remove and flip the housing. Remove the four bolts holding the impellor on. Replace impellor.
7. Reverse steps 7 through 1.
