IRIS-4 160
Quick Installation and
Maintenance Guide
3
2
IRIS-4 160
CONTENTS
1. Introduction .......................................................................................3
2. Product Features
..................................................................................3
3. Package Contents
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4. BoardConguration
...............................................................................4
5. Before You Start
...................................................................................5
6. Installing the IRIS-4 160 Dialler
.....................................................................6
6.1. Mounting
....................................................................................6
6.2. Power
........................................................................................6
6.3. Backup Batteries (optional)
....................................................................6
6.4. Connections
..................................................................................7
6.5. 4G/3G/2G SIM Card
.........................................................................8
6.6. Dial Capture
.................................................................................8
6.7. Pin Inputs
....................................................................................8
6.8. Switch On
....................................................................................9
6.9. Configuration
................................................................................9
6.10. Panel Configuration
..........................................................................14
6.11. Testing
......................................................................................14
7. Maintenance
......................................................................................15
7.1. Confirm Current Status
......................................................................16
7.2. Checking Battery Status
......................................................................16
7.3. Replacing Batteries
...........................................................................16
7.4. Check Software Version/Reflash
...............................................................17
7.5. Communication Path Checks
.................................................................17
7.6. Test Alarm Panel Alarms and Communication to Monitoring Centre
............................17
8. Specications
.....................................................................................18
1. INTRODUCTION
2. PRODUCT FEATURES
FEATURES
Fire retardant enclosure
NiMH battery backup
Ethernet
4G/3G/2G
Dial capture
Relays
Inputs (Pins)
Serial RS485
Serial TTL
RS232 (Basic)
Text messaging
Multi language menus
VoIP & SIP services
IRIS-4
160
•
>15 hrs
1
•
•
3
4
 • 
 •
 •
 •
 •
 •
The IRIS-4 160 offers a new concept in Alarm over
IP (AoIP) providing cost effective AoIP for the
residential sector. IRIS-4 160 is certified as suitable
for all Grade 2 systems with an Alarm Transmission
System (ATS) configuration up to SP3 for single path,
or ATS configuration DP2 for dual path.
The IRIS-4 160 is based on the successful IRIS Touch
NG range of AoIP diallers with the same hardware
and software used in all IRIS diallers; with the same
level of security and features provided to military,
governments, banks and commercial industry but
now also available to the residential sector.
Polling and alarm transmission are performed via the
Ethernet, Wi-Fi or 4G/3G/2G communications to
the monitoring centre using the IRIS Secure Apps
monitoring software.
Using AddSecure’s advances in hardware and soft-
ware, the IRIS-4 160 is unique in providing battery
backup for mains over 15 hours support in the case
of mains power source failure. This backup is pro-
vided with only 4 NiMH AA rechargeable batteries,
which allow a longer replacement life and a smaller
design.
Note 1: The 15 hours standby is based on 15 min-
ute polling with the recommended quality batteries.
May reduce performance using a faster polling or
other system loading.
Note 2: You can fit the IRIS-4 160 without batteries
and will run as a standalone device without battery
backup.
This manual gives a quick guide to the installation
of products from the IRIS-4 160. For the full
engineering manual, including multi-lingual versions,
please visit our website http://www.addsecure.com
