AddSecure IRIS-4 50 - Package Contents; Terminal Layout

IRIS-4 50
Quick Installation and
Maintenance Guide
2
2. TERMINAL LAYOUT1. PACKAGE CONTENTS
• Terminal
• Cable harness loom
• Cellular T-bar antenna (2.5m long)
• Velcro mounting pads
• Adhesive mounting pad
• Cable tie wrap for mounting
① = Signal strength/default button
② = USB micro connector
③ = Cable harness loom,
with color coded identification
④ = Cellular antenna connection
⑤ = Terminal Activation Code (TAC)
⑥ = Not in use
⑦ = Panel interface status indicator (red)
⑧= Cellular status indicator (yellow)
⑨= Terminal status LED indicator (green)












 
OPT SIM
3
4
9
8
7
6
1
2
5
