ADEEPT Hexapod - Assemble Leg Mechanism

www.adeept.com
Assemble the following components
22
Effect diagram after assembling
M3*10
Screw
X3
Component that
has been fitted
with nuts
Pay attention to the direction,
don't reverse.
Front view
side view
Note: assemble first
in this way.
