ADEEPT Hexapod - Assemble Rocker Arm

www.adeept.com
Assemble the following components
24
Effect diagram after assembling
M1.7*6*6 self-tapping
Screw X1
M2.5*8 Screw
X1
rocker arm
X1
Front view
Back view
Note: Do not reverse the direction of the
servo after assembly. This has already been
assembled. Then follow the same steps to
assemble the remaining two feet on the left
side.
Note: The two components are
connected together by a
rocker arm. The connection of
the rocker arm has been
illustrated above.
