Assemble the following components
37
Effect diagram after assembling
M1.4*6 screw
X4
Note: The LED module has an
input (IN) with a white edge and
an output (OUT) without white
edge. If the LED does not light up
in yellow normally, then check if
the input and output are
reversed.
3-
Pin Wire
X2
