20
www.adeept.com
Fix one section of the 18650 Battery Holder Set to acrylic
Assemble the following components
Effect diagram after assembling
M3*12 Countersunk
Head Screw x1
18650 Battery
Holder Set
X1
M3*35 Screw x4
M3 Nut x5
Pay attention todistinguishing
the placement direction of the
motor
