VCC
-
GND
The schematic diagram:
In this experiment, by programming the Raspberry Pi, we collect the analog values output
by the Thermistor module through CH0 of the ADC0832, change it to digital values and
display them on terminal.
Experimental Procedures
Step 1: Build the circuit
1
2
3
P1
Header10K
R1
A
+
-
LED
220Ω
R2
GND
VCC
VCC
GND
VCC
GND
RT
Thermistor
