AIR COMPRESSORS
DIRECT & BELT DRIVEN MANUALS
15
CHECKING THE FUEL LEVEL
RECOMMENDED FUEL
Only use standard unleaded petrol
1. Check the fuel level on the fuel gauge. The fuel gauge will show as red
when you have fuel in the tank turning white as the fuel level decreases.
2. To add fuel, open the fuel filter cap.
3. Just inside the fuel tank is a fuel filter which catches any contaminants
as you refuel.
4. Slowly add fuel to the fuel tank watching the fuel level gauge as you do so.
WARNING: ALWAYS REFUEL IN A WELL VENTILATED AREA AWAY
FROM ANY HEAT SOURCES.
WARNING: ALLOW THE UNIT TO COOL DOWN BEFORE REFUELLING.
WARNING: DO NOT LEAVE FUEL WITHIN THE REACH OF CHILDREN.
5. Replace the fuel filter cap securely.
USING THE COMPRESSOR
STARTING THE ENGINE
1. Set the fuel valve to the ON position.
2. Move the choke lever to the “choke” position.
3. Ensure that the “Engine Switch” is on and the air release valve is open on
the air receiver.
4. Pull metal lever as shown in image 4 (on left) before starting. After engine
has reached normal RPM (running speed), return lever to original position.
5. Proceed by pulling the recoil start – until unit has started (COMPRE-070
and COMPRE-071 models)
6. Insert the key into the ignition. (COMPRE-705 model)
7. Turn and hold the key in the START position. (COMPRE-705 model)
8. Once the engine has warmed up,set the choke lever to the RUN Position
WARNING: ONCE THE COMPRESSOR HAS STARTED, RELEASE THE STARTING
HANDLE SLOWLY TO AVOID INJURY/DMAGE AS IT RECOILS.
SHUTTING DOWN THE COMPRESSOR
To stop the compressor in an emergency simply set the engine switch to OFF.
NOTE: Do not overfill the
fuel tank.
3
5
4
6
2
