PREPARATION FOR START UP
Open the packing of the device and remove all protective tapes.
Opening the cover of the device, take out the instruction manual.
Place the devices with adjustable legs by adjusting their legs and the device with fixed legs by aligning the ground.
Connect the elbowed part of the supply hose the solenoid valve of the device,the other end,to the tap.
Clamp one end of drainage hose to the drainage outlet of the machine.Connect the other end of it to sewer system coming from the
ground.
Drainage hose must not be twisted, folded, and bent more than 90º
Supply water must be at 50ºC in temperature and 202 to 404 kpa in pressure
If the connection to sewer system on the ground is above the drainage outlet of the machine, a drainage pump must be used.
If water pressure is higher than 404 kpa, a pressure reducer valve must be used.
If the water pressure is lower than 202 kpa, a water pressurizing pump must be used.
Supply water of the machine must be a 10 to 15 º Fr.
If it is not so, a water softening device must be used.
Drainage line to sewer system on the ground, which drainage pipe was connected to, must have a siphon, in order to prevent bad
smells.
Required voltage a washing machine is 380-400 AC V / 50 Hz.
Make a grounding connection and be sure that this connection has been made correctly.
Be sure that there is energy supply in the system.
On the condition that you have fulfilled all requirement for operating the device, your device is ready for working.
FINAL CHECK BEFORE START UP
o The users should fulfill the following last-controls by accepting the required couplings of fresh water, electric, wastewater ,
installations to be carried out by the authorized technicians;
o You must be sure that the power supply and grounding installation are ensured as required in leaflets of electrical equipment.
o You must be sure that the feeding water has been installed and the water vane is turned on.
o You must be sure that the wastewater installation was done properly and discharging hose was coupled with discharging pipe tightly.
10. START UP
Have a specialist electrician your device working 220-230 V connect to the K-automat fuses group.
Device must not be operated without being made adequate grounding and from the electricity source, which do not have leak current
relay.
Water supply connection must be made and its valve must be open
Water drainage connection must be made.
Before placing things into the baskets, solid wastes must be cleaned and subjected to pre-washing by washing buttery with sprayer.
Do not place more dirty dishes than stated in the Table into baskets.
Do not use any detergent for pre-washing.
Keep the very dirty dishes (waiting ones more than 2-3 hour) under water until complete dissolving
Do not wash materials made of plastic.
Use foam controlled liquid detergent in your machine.
Have the detergent firm dosing apparatus to supply detergent into your machine connect.
