In the field “Start Bit” is used for the “Bit” data. It is possible to select the bit of the selected Position where mapping the data;
If the field “Swap” is checked, the bytes’ order is reversed;
If the field “Swap W” is checked, the words’ order is reversed;
In the field “Mnemonic” a description of the data inserted in the row is defined.
