CHARACTERISTICS:
The HD67660-A1 is a PROFINET / EtherNet/IP Converter.
It allows the following characteristics:
Up to 500 bytes in reading and 500 bytes in writing on EtherNet/IP side;
Two-directional information between EtherNet/IP and PROFINET;
Mountable on 35mm Rail DIN;
Wide power supply input range: 8…24V AC or 12…35V DC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67660 software on your PC in order to perform the following:
Define the parameter of the PROFINET;
Define the parameter of the Ethernet/IP.
