PowerLab Teaching Series - Owner’s Guide
23
Figure 3-4
The Stimulator dialog,
Windows
Choose how simulation should start
Choose a stimulus
type preset
Specify a custom
stimulus
waveform
Set stimulus
parameters
Configure the
range of valid
parameter values
in the Parameter
Settings dialog
