ADInstruments POWERLAB TEACHING SERIES User Manual

PowerLab Teaching Series - Owner’s Guide
50
Table 5.1
Error
No.
Red Light Sequence Meaning F a t a l /
Non-Fatal
Error Name
-2 LNG, LNG RAM test failed Fatal eRAMFailure
-4 LNG, LNG, LNG, LNG ROM check sum was wrong Fatal eROMCheckBad
-7 SHRT, SHRT, LNG, LNG, LNG Required resource missing Non-Fatal eRsrcMissing
-8 SHRT, LNG, SHRT, SHRT, SHRT Real–time clock won't reset or increment Non-Fatal eClkBad
-11 SHRT, LNG, SHRT, LNG, LNG Command FIFO flags don't read correctly Non-Fatal eCmdFIFO
-12 SHRT, LNG, LNG, SHRT, SHRT ADC FIFO flags don't read correctly Non-Fatal eADCFIFO
-13 SHRT, LNG, LNG, SHRT, LNG DAC FIFO flags don't read correctly Non-Fatal eDACFIFO
-14 SHRT, LNG, LNG, LNG, SHRT DAC state machine won't run Non-Fatal eDACSysBad
-15 SHRT, LNG, LNG, LNG, LNG ADC state machine won't run Non-Fatal eADCTimeOut
-16 LNG, SHRT, SHRT, SHRT, SHRT ADC bad zero: p == value read Non-Fatal eADCZero
-17 LNG, SHRT, SHRT, SHRT, SHRT EEROM wouldn't read Non-Fatal eEEROMBad
-18 LNG, SHRT, SHRT, LNG, SHRT ADC FIFO capacity/speed tests failed Non-Fatal eADCSysBad
-30 LNG, LNG, LNG, LNG, SHRT ADC won’t read consistently Non-Fatal eChanNoisy
