ADJ 1223200091 - Page 23

23
DMX TRAITS
CHANNEL
DMX
VALUES
FUNCTION
5CH
8CH
A
8CH
B
9CH
10CH
A
10CH
B
12CH 13CH 16CH 20CH
6 11 14 18
Dim Speed (continued)
152 2.0s
153 3.0s
154 4.0s
155 5.0s
156 6.0s
157 7.0s
158 8.0s
159 9.0s
160 10.0s
161 - 255 Default to unit setting
7 12 15 19
Dim Curves
000 - 020 Square
021 - 040 Linear
041 - 060 Inv. Squa.
061 - 080 S. Curve
081 - 255 No function
8 13 16 20
Refresh Rates
000 - 015 Default to unit setting
016 - 030 900 Hz
031 - 045 1000 Hz
046 - 060 1100 Hz
061 - 075 1200 Hz
076 - 090 1300 Hz
091 - 105 1400 Hz
106 - 120 1500 Hz
121 - 135 2500 Hz
136 - 150 4000 Hz
151 - 165 5000 Hz
166 - 180 10,000 Hz
181 - 195 15,000 Hz
196 - 210 20,000 Hz
211 - 225 25,000 Hz
226 - 255 No function
