ADJ 18P Hex - DMX Traits

DMX TRAITS
CHANNEL
DMX VALUE FUNCTION
6-CH 7-CH 8-CH 12-CH
1 1 1 1 000 - 255
Red, 0% - 100%
2 2 2 2 000 - 255
Green, 0% - 100%
3 3 3 3 000 - 255
Blue, 0% - 100%
4 4 4 4 000 - 255
White, 0% - 100%
5 5 5 5 000 - 255
Amber, 0% - 100%
6 6 6 6 000 - 255
U V, 0% - 100%
7 7 7 000 - 255
Master Dimmer, 0% - 100%
8 8
Strobing
000 - 031 LED O
032 - 063 LED On
064 - 095 Strobing, slow to fast
096 - 127 LED On
128 - 159 Pulse Strobing, slow to fast
160 - 191 LED On
192 - 223 Random Strobe, slow to fast
224 - 255 LED On
9 000 - 255
Color Macros, see Color Macros Chart
10
Programs
000 - 020 No Program
021 - 040 30 Color Change
041 - 060 6 Color Change
061 - 080 Color Fade
081 - 100 Sound Active 30 Color Change
101 - 120 Sound Active 6 Color Change
121 - 140 Sound Active 6 Color Fade
141 - 255 No Program
11 000 - 255
Program Speed, slow to fast
Sound Sensitivity, least to most sensitive
12
Dimmer Mode
000 - 020 Standard
021 - 040 Stage
041 - 060 TV
061 - 080 Architectural
081 - 100 Theatre
101 - 255 Default Dimmer Setting
When Channel 10 is between the values of 21-80, Channel 11 will control the color change speed and color fade speed.
When Channel 10 is between the values of 81-140, Channel 11 will control the sound sensitivity.
