ADJ FLAT PAR TRI7XS - 1 Channel DMX Mode Functions; 2 Channel DMX Mode Functions; 3 Channel DMX Mode Functions; 4 Channel DMX Mode Functions

ADJ Products, LLC - www.adj.com - Flat Par TRI7XS User Manual Page 15
Channels 1, 2, and 3 will not work, when Channel 4 is being
used.
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
5 STROBING
0 - 15 NOTHING
16 - 255 STROBING SLOW - FAST
6 MASTER DIMMER
0 - 255 0% - 100%
Flat Par TRI7XS 6 Channel Mode
Channels 1, 2, and 3 will not work, when Channel 5 is being
used.
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 MASTER DIMMER
0 - 255 0% - 100%
5 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
Flat Par TRI7XS 5 Channel Mode
ADJ Products, LLC - www.adj.com - Flat Par TRI7XS User Manual Page 14
Flat Par TRI7XS 2 Channel Mode
Channel Value Function
1 0 - 255 COLOR MACROS
(See 1 Channel DMX mode for colors)
2 0 - 255 DIMMER 0% - 100%
Flat Par TRI7XS 3 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
Flat Par TRI7XS 4 Channel Mode
Channel Value Function
1 RED
0 - 255 0% - 100%
2 GREEN
0 - 255 0% - 100%
3 BLUE
0 - 255 0% - 100%
4 MASTER DIMMER
0 - 255 0% - 100%
