Focus Spot 2X Installation
Screw one clamp via a M12 screw and nut into the bracket. Attach the bracket to the respective holes
located on the bottom of the Focus Spot 2X. Tighten and secure the bracket screws. Pull the safety
cable through the opening(s) located on the base plate and over the trussing system or a safe xation
spot. Insert the end in the carabine and tighten the safety screw.
NOTICE: The suitable enviromental temperature for this lighting xture is between -25˚ C to 45˚ C.
Do not place this lighting xture in an enviroment where the temperatures are under or above the
temperatures stated above. This will allow the xture to run at its best and help prolong the xture
life.
SAFETY CABLE
ATTACHMENT POINT
SAFETY CABLE
ATTACHMENT POINT
BRACKET
ATTACHMENT POINT
BRACKET
ATTACHMENT POINT
SAFETY CABLE
(NOT INCLUDED)
CLAMP
(NOT INCLUDED)
BRACKET
