On-Board System Menu. The Ikon Prole comes with an easy to
navigate system menu. This next section will detail the functions of
each command in the system menu. Please read the next section
thoroughly!
To access the main menu press the MENU button. Press the UP or
DOWN buttons until you reach function you wish to change. When
you reach the function you wish to change press the ENTER button.
When a function is selected use the UP or DOWN buttons to change
the function settings. Once your changes are made press the ENTER
button, and then press and hold the MENU button for at least three
seconds to conrm and lock the change into the system memory. If
the MENU button is not pressed and held within eight seconds the
xture will automatically conrm and lock the change into the system
memory. To exit without making any changes press the MENU button.
ADDR - DMX Address Setting.
1. Press the MENU button until “ADDR” is displayed, press
ENTER.
2. The current DMX address will now be displayed and ashing.
Press the UP or DOWN buttons to nd your desired address.
Press ENTER to set your desired DMX address.
NOTE: If after you connect your DMX controller the unit does
not fall into DMX mode, press and hold the MENU button for at
least 3 seconds.
SLND - This will let you set unit as a master or slave in
a master/slave conguration.
1. Press the MENU button until “SLND” is displayed, press
ENTER. “MAST” or “SL 1” will be displayed.
2. Press the UP or DOWN buttons until your desired setting is
displayed, press ENTER to conm and exit.
DNST - This mode can be used as a precaution mode,
that in case the DMX signal is lost, interrupted, or power is
lost, the operating mode chosen in the setup is the running
mode the xture will go into when the DMX signal is lost. You
can also set this as the operating mode you would like the
unit to return to when power is applied.
1. Press the MENU button until “DNST” is displayed, and either
“MASL”, “BLND”, or “LAST” will be displayed beneath.
2. Press ENTER and the bottom choice will begin to ash. Use
the UP or DOWN buttons to choose an operating mode you
would like the unit to start up in when power is applied or the
DMX signal is lost.
• MASL (Master Slave) - If the DMX signal is lost or power is
applied, the unit will automatically go into Master Slave mode
and run a built-in show.
• BLND (Blackout) - If the DMX signal is lost or interrupted, the
unit will automatically go into stand by mode.
• LAST - If the DMX signal is lost the xture will stay in the last
DMX setting. If power is applied and this mode is set, the unit will
automatically go into the last DMX set up.
3. Press ENTER to conrm your desired set up.
DIND - This will let select your desired dimmer curve.
1. Press the MENU button until “DIND” is displayed, and press
ENTER. 1 of 5 dimmer curves will be displayed. “STDA” (stan-
dard), “STGE” (stage), “TV” (TV), “ARAL” (Architectural), or
“THAL” (Theatre). See the dimmer curve chart on page 28 for
more info.
2. Press the UP or DOWN buttons to nd your desired dimmer
curve and press ENTER to conm and exit.
