ADJ Products, LLC - www.adj.com - Prole Panel RGBA User Manual Page 19 ADJ Products, LLC - www.adj.com - Prole Panel RGBA User Manual Page 20
Profile Panel RGBA 32 Channel Mode
Channel Value Function
17 RED SECTION 5
0 - 255 0% - 100%
18 GREEN SECTION 5
0 - 255 0% - 100%
19 BLUE SECTION 5
0 - 255 0% - 100%
20 AMBER SECTION 5
0 - 255 0% - 100%
21 RED SECTION 6
0 - 255 0% - 100%
22 GREEN SECTION 6
0 - 255 0% - 100%
23 BLUE SECTION 6
0 - 255 0% - 100%
24 AMBER SECTION 6
0 - 255 0% - 100%
25 RED SECTION 7
0 - 255 0% - 100%
26 GREEN SECTION 7
0 - 255 0% - 100%
27 BLUE SECTION 7
0 - 255 0% - 100%
28 AMBER SECTION 7
0 - 255 0% - 100%
29 RED SECTION 8
0 - 255 0% - 100%
30 GREEN SECTION 8
0 - 255 0% - 100%
31 BLUE SECTION 8
0 - 255 0% - 100%
32 AMBER SECTION 8
0 - 255 0% - 100%
See Page 21 for the Section Layout
Profile Panel RGBA 32 Channel Mode
Channel Value Function
1 RED SECTION 1
0 - 255 0% - 100%
2 GREEN SECTION 1
0 - 255 0% - 100%
3 BLUE SECTION 1
0 - 255 0% - 100%
4 AMBER SECTION 1
0 - 255 0% - 100%
5 RED SECTION 2
0 - 255 0% - 100%
6 GREEN SECTION 2
0 - 255 0% - 100%
7 BLUE SECTION 2
0 - 255 0% - 100%
8 AMBER SECTION 2
0 - 255 0% - 100%
9 RED SECTION 3
0 - 255 0% - 100%
10 GREEN SECTION 3
0 - 255 0% - 100%
11 BLUE SECTION 3
0 - 255 0% - 100%
12 AMBER SECTION 3
0 - 255 0% - 100%
13 RED SECTION 4
0 - 255 0% - 100%
14 GREEN SECTION 4
0 - 255 0% - 100%
15 BLUE SECTION 4
0 - 255 0% - 100%
16 AMBER SECTION 4
0 - 255 0% - 100%
See Page 21 for the Section Layout
