Quad Phase HP Power Cord Daisy Chain
Quad Phase HP UC3 Control
With this feature you can connect the xtures to one another using the locking
power input and output sockets. The quantity that can be connected is 5 xtures
maximum. After 5 xtures you will need to use a new power outlet. They must be
the same xtures. DO NOT mix xtures.
Blackout Blackout the Unit
Functions
1. Synchronous strobe.
2. Two light strobe.
3. Sound control.
Rotation speed (1-8).
Mode Strobe(LED OFF) Chase(LED ON)
Quad Phase HP DMX Traits
Channel Value Function
1
0 - 16
17 - 33
34 - 50
51 - 67
68 - 84
85 - 101
102 - 118
119 - 135
136 - 152
153 - 169
170 - 186
187 - 203
204 - 220
221 - 237
238 - 255
COLOR SELECTON
COLOR 1
COLOR 2
COLOR 3
COLOR 4
COLOR 5
COLOR 6
COLOR 7
COLOR 8
COLOR 9
COLOR 10
COLOR 11
COLOR 12
COLOR 13
COLOR 14
COLOR 15
2
0 - 9
10 - 120
121 - 134
135 - 245
246 - 249
250 - 255
ROTATION
NO ROTATION
CLOCKWISE FAST - SLOW
NO ROTATION
COUNTER-CLOCKWISE SLOW-FAST
NO ROTATION
SOUND ACTIVE
3 0
1 - 255
STROBING
OFF
STROBING SLOW - FAST
4 0 - 15
16 - 255
SHUTTER OPEN
OFF
OPEN
