ADJ Startec RAYZER - Overview

ADJ Products, LLC - www.adj.com - Rayzer User Manual Page 11
Rayzer Overview
1
2
3
4
1
2
6
3
4
55
1.Display:Usedtoshowthevariousmenus and theselectedfunctions.
2．
Buttons:
MENU
 Toselecttheprogramming functions
UP 
 Togoforwardintheselectedfunctions
DOWN
 Togobackwardintheselectedfunctions
ENTER
 Toconrmtheselectedfunctions
3.DMXIN/OUT: DMX512 Connections. Use 3-Pin XLR cables to link the units together, or
to connect a unit to a DMX controller.

4.POWERIN/FUSE (2Amp)
:
The Power In socket is used to connect to a power source.
The fuse protects the unit from any damage from over current.
5.Microphone:
6. Key forLaser : This key is used to turn the Laser diode On/O. (EU verion only)
Europe Version
US Version
Receives music output while in Sound Active mode.
