CUT & ALARM
Signal
Action
L+
CUT & ALARM interface is
not supplied with a voltage.
The CUT & Alarm
functionality is not available.
L+
CUT & ALARM interface is
supplied with a voltage.
The CUT & Alarm
functionality is given.
INT
An internal Cut is triggered
EXT
An external Cut is triggered
AL
An Alarm is triggered
LAN-IN
Signal
Action
PoE
The device is not supplied
with a power.
PoE
The device is provided with
voltage via PoE and is ready
for operation.
LINK
The interface is connected to
a remote station and is ready
for operation.
ACT
Displays the traffic between
the firewall and remote.
