specifications
amplifier section
power output 4Ω(watts)1 50/channel
150/bridged channel pair
power output 2Ω (watts)2 75/channel
distortion all channels driven 0.1% 20Hz to 20,000Hz
frequency response ±1dB 10Hz to 30,000Hz
signal-to-noise ratio full
bandwidth @ rated output power >90dB
damping factor @ output
connector full bandwidth >150
input sensitivity 100mV to 8Vrms for full output
input impedance 47 kΩ
recommended fuse type
P850.2 2 X 40 ATC
P650.2 2 X 30 ATC
P450.2 2 X 20 ATC
crossover section3
ch 1 & 2 high-pass
ch 3 & 4 high-pass & low-pass
ch 5 & 6 high-pass & low-pass (P850.2), low-pass (P650.2)
ch 7 & 8 low-pass
dimensions
P850.2 13" X 2" X 16 1/8" (330mm X 50mm X 410mm)
P650.2 13" X 2" X 14 1/8" (330mm X 50mm X 359mm)
P450.2 13" X 2" X 11 1/8" (330mm X 50mm X 283mm)
1. All channels driven, continuous FTC rated 4Ω load, 20Hz to 20,000Hz, <0.1% THD,
power input voltage at 13.8DVC.
2. All channels driven, continuous FTC rated 2Ω load, 20Hz to 20,000Hz, <0.1% THD,
power input voltage at 13.8DVC.
3. All channels are selectable with infinitely variable adjustments from 45Hz to 5,000Hz
with a slope rate of 12dB/octave and a "Q" of .707.
25
