5
–
RESTORE REPORT CODES (
✱
70 –
✱
76)
✱
70
ALARM RESTORE RPT CODE
[1] Any non-zero entry enables CID report.
✱
71
TROUBLE RESTORE RPT CODE
| [10] Any non-zero entry in first digit enables CID report.
✱
72
BYPASS RESTORE RPT CODE
| [00] Any non-zero entry in first digit enables CID report.
✱
73
AC RESTORE RPT CODE
| [00] Any non-zero entry in first digit enables CID report.
✱
74
LOW BAT RESTORE RPT CODE
| [10] Any non-zero entry in first digit enables CID report.
✱
75
RF XMTR LO BAT RST RPT CODE
| [10] Any non-zero entry in first digit enables CID report.
UL: must be enabled if wireless devices are used
✱
76
TEST RESTORE RPT CODE
| [10] Any non-zero entry in first digit enables CID report.
OUTPUT AND SYSTEM SETUP (
✱
77 –
✱
93)
*
77
DAYLIGHT SAVINGS TIME
START\END MONTH
| [4][10]
0 = Disabled
1-12 = month (1 = January, 2 = February, etc)
*
78
DAYLIGHT SAVINGS TIME
START\END WEEKEND
| [1][5]
0 = disabled, 1 = first, 2 = second, 3 = third
4 = fourth, 5 = last, 6 = next to last, 7 = third to last
✱
84
AUTO STAY ARM
[0]
0 = no, 1 = partition 1 only
2 = partition 2 only, 3 = both partitions
✱
85
CROSS ZONE TIMER
This option not for use in UL installations.
[0]
0 = 15 seconds 6 = 2-1/2 min #+12 = 8 min
1 = 30 seconds 7 = 3 min #+13 = 10 min
2 = 45 seconds 8 = 4 min #+14 = 12 min
3 = 60 seconds 9 = 5 min #+15 = 15 min
4 = 90 seconds #+10 = 6 min
5 = 2 minutes #+11 = 7 min
(assign cross zones on zone list 4, with *81 Menu mode)
✱
86
CANCEL VERIFY
[0]
0 = no, 1 = yes
✱
89
EVENT LOG FULL REPORT CODE
| [00]
Enter any digit (other than "0") in the first box, to enable
report (entries in the second box are ignored)
✱
90
EVENT LOG ENABLES
[12]
0 = None; 1 = Alarm/Alarm Restore
2 = Trouble/Trouble Restore;
4 = Bypass/Bypass Restore;
8 = Open/Close.
Example:
To select “Alarm/Alarm
Restore”, and “Open/Close”, enter 9 (1 + 8); To select
all, enter #15.
NOTE
:
System messages are logged when any non-
zero selection is made.
✱
91
OPTION SELECTION
[8]
0 = None
1 = Bell Supervision UL: required for fire alarm install
4 = AAV UL: do not use AAV
8 = Exit Delay Restart
Multiple choice example: for AAV (4) + Exit Delay
restart (8) enter # + 12; for all (1 + 4 + 8), enter # + 13.
✱
92
PHONE LINE MONITOR ENABLE
UL: see Inst. Instructions for requirements
[0,0]
Digit 1:
: 0 = disabled, 1-15 = 1 min - 15 min
Digit 2
:
0 = Touchpad display when line is faulted
1 = Touchpad display plus touchpad trouble sound
2 = Same as “1”, plus programmed output device
STARTS. If either partition is armed, external sounder
activates also.
NOTE:
Output Device must either be
programmed to be STOPPED in field
✱
80 or
STOPPED by Code + # + 8 + output number.
✱
93
No. OF REPORTS IN ARMED PERIOD
PER ZONE (Swinger Suppression)
[0]
0 = Unlimited Reports; 1 = 1 report; 2 = 2 reports
UL: must be “0”
DOWNLOAD INFORMATION (
✱
94,
✱
95)
✱
94
DOWNLOAD PHONE No.
| | | | | | | | | | | | | | | | | | |
Enter up to 20 digits, 0–9; #+11 for '
✱
'; #+12 for '#'; #+13 for a 2-second pause. Do not fill unused
spaces. If fewer than 20 digits, exit field by pressing
✱
(and press 95, if entering next field). To clear
entries from field, press
✱
94
✱
. UL: downloading may be performed only if a technician is at the site.
✱
95
RING COUNT FOR DOWNLOADING
[15]
0 = Disable Station Initiated Download;
1–14 = number of rings (1–9, # +10 =10, # +11 =11,
# +12 =12, # +13 =13, # +14 =14);
15 = answering machine defeat (# +15 =15).
NOTE:
Do not enter “0” if using 4285/4286 Phone Module.
