7
–
✱
177
DEVICE DURATION 1, 2
(used in *80 Menu mode-Device Actions 5/6)
[0] [0]
1 2
0 = 15 seconds 6 = 2-1/2 min #+11 = 7 min
1 = 30 seconds 7 = 3 min #+12 = 8 min
2 = 45 seconds 8 = 4 min #+13 = 10 min
3 = 60 seconds 9 = 5 min #+14 = 12 min
4 = 90 seconds #+10 = 6 min #+15 = 15 min
5 = 2 minutes
SYSTEM OPTIONS *180-*181
✱
180
SINGLE ZONE BYPASS
[0]
0 = disable; 1 = enabled
✱
181
50/60 HERTZ AC OPERATION
[0]
0 = 60 Hz; 1 = 50 Hz
✱
182
CONFIGURABLE ZONE TYPE 90
12345678910
Make the appropriate entry for each digit, 1-10, based on the charts provided on the
next page. Each digit’s entry is the sum of the values of its selected options
(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).
UL: Do not configure zones as a fire alarm or UL burglar alarm zone.
✱
183
ZONE TYPE 90 REPORT CODES
IMPORTANT:
Use existing Contact ID®
codes, if appropriate, or define unique codes
in CID code range 750-789. See important
note in installation instructions.
90 ALARM ID: XXX
TROUBLE ID: XXX
Enter the desired 3-digit Contact ID
®
report codes for
alarms and troubles occurring on zones assigned to
this zone type. Enter the codes sequentially (all 6
digits). When entering digits, [#] moves cursor back, [
∗
]
moves forward. Press [
∗
] when done to continue.
✱
184
CONFIGURABLE ZONE TYPE 91
12345678910
Make the appropriate entry for each digit, 1-10, based on the charts provided on the
next page. Each digit’s entry is the sum of the values of its selected options
(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).
UL: Do not configure zones as a fire alarm or UL burglar alarm zone.
✱
185
ZONE TYPE 91 REPORT CODES
IMPORTANT:
Use existing Contact ID®
codes, if appropriate, or define unique codes
in CID code range 750-789. See important
note in installation instructions.
91 ALARM ID: XXX
TROUBLE ID: XXX
Enter the desired 3-digit Contact ID
®
report codes for
alarms and troubles occurring on zones assigned to
this zone type. Enter the codes sequentially (all 6
digits). When entering digits, [#] moves cursor back, [
∗
]
moves forward. Press [
∗
] when done to continue.
TOUCHPAD OPTIONS *190-*196 (
NOTE
: Options for touchpad address 16 are set by the factory and cannot be changed.)
NOTE:
Each touchpad must be assigned a unique address. Touchpads programmed with the same address will give
unpredictable results.
∗
190
TOUCHPAD 2 ADDRESS 17
[0] [0]
Part. Sound
Partition: 0 = keypad disabled; 1-3 = part. no. (3 = com)
Sound: 0 = no suppression
1 = suppress arm/disarm and E/E beeps
2 = Suppress chime beeps only
3 = suppress arm/disarm, E/E, and chime
beeps
∗
191
TOUCHPAD 3 ADDRESS 18
[0] [0]
Part. Sound
See field
∗
190 for entries.
∗
192
TOUCHPAD 4 ADDRESS 19
[0] [0]
Part. Sound
See field
∗
190 for entries.
∗
193
TOUCHPAD 5 ADDRESS 20
[0] [0]
Part. Sound
See field
∗
190 for entries.
∗
194
TOUCHPAD 6 ADDRESS 21
[0] [0]
Part. Sound
See field
∗
190 for entries.
∗
195
TOUCHPAD 7 ADDRESS 22
[0] [0]
Part. Sound
See field
∗
190 for entries.
∗
196
TOUCHPAD 8 ADDRESS 23
[0] [0]
Part. Sound
See field
∗
190 for entries.
∗
197
EXIT TIME DISPLAY INTERVAL
[0]
0 = no display; 1-5 = seconds between display refresh
∗
198
DISPLAY PARTITION NUMBER
(for Custom Display Touchpads)
[0]
0 = no; 1 = yes (partition no. appears on Custom
Display)
∗
199
ECP FAIL DISPLAY
[0]
0 = 3-digit display (“1” + device address)
1 = 2-digit fixed-display as “91”
