RF Tx Menu
Item Function Options
Transmit Allows the operator to enable or disable
the Main RF output. If Transmit is enabled
and any value for Type, Frequency,
Rolloff, Symbol Rate, or Interface Rate is
changed, then Transmit will be
automatically disabled. However, the
monitor output will remain active.
Disable
Enable
Type Allows the selection of the mod type. DVBS
DVBS-2
Mode This control allows the operator to select
the desired modulation mode and FEC
code rate.
We display all possible ranges
available via our device in the
Front Panel. This list will differ
from the list found in the web
UI as it only shows those
options available based on the
feature keys found.
QPSK-1/2
QPSK-2/3
QPSK-3/4
QPSK-5/6
QPSK-6/7
QPSK-7/8
QPSK-1/4
QPSK-1/3
QPSK-2/5
QPSK-3/5
QPSK-4/5
QPSK-8/9
QPSK-9/10
8PSK-3/5
8PSK-2/3
8PSK-3/4
8PSK-5/6
8PSK-8/9
8PSK-9/10
16QAM-3/4
16QAM-7/8
16APSK-2/3
16APSK-3/4
16APSK-4/5
16APSK-5/6
16APSK-8/9
16APSK-9/10
32APSK-3/4
32APSK-4/5
32APSK-5/6
32APSK-8/9
32APSK-9/10
Frequency Allows the operator to enter the desired
output frequency of the main RF output
port.
7039: 950MHz - 1.75GHz
LBAND
7139: 950MHz - 2.15GHz
LBAND
50MHz - 180MHz IF
** The monitor output
frequency for the EN-XX IF is
fixed at 1.080GHz. The monitor
output frequency for the EN-XX
L-Band tracks with the main RF
To Next Page
