IP Tx Menu
Note: this is a parallel menu. It has four index. Use the left or right arrows to navigate to
desired index.
Item Function Options
Mode Enables IP Egress. Off
Send
Tx IP Address IP Address on which a transport
stream is transmitted.
user-defined using the numeric
keypad
Tx Port port assignment used for
transmitting a multicast
user-defined using the numeric
keypad
DVB per IP Allows the operator to select how
many DVB packets to insert into
each Ethernet frame.
1
4
7
RTP allows for sequence numbering
and timing; editable if Multicast
Mode is set to 'Send'
On
Off
FEC Mode Forward Edge Correction; selects
on/off. When selected, sends two
FEC RTP streams in addition to a
source RTP stream enabling a
receiver to reconstruct missing
packets in the source stream.
OFF
ON
MAXBURST
BURST
LOWLATENCY
FEC L affects the maximum
burstpacket loss that can be
recovered
4-20
FEC D defines latency involved in
burstrecovery
4-20
TOS Allows the operator to sets the
TOS bits in the IPv4 header of
the TSoIP payload
0 = Normal service
2 = Minimize monetary cost
4 = Maximum reliability
8 = Maximize through put
16 = Minimize delay
TTL Time-to-Live; specifies the
number of iterations or
transmissions the packet can
undergo before it is discarded
user-defined using the numeric
keypad
Tx Connector sets the physical connector (on Ethernet
