Adtech CNC Technology Co., Ltd. 8. Program saving & editing
- 25 -
8.
Program saving & editing
8.1 Saving the program in the memory
8.1.1 Keypad input (new program)
Create new program in the memory with the keypad, and the step follows:
In the main menu, press [Edit] to enter program edit interface;
Press [File] to enter file operation interface;
Select [New] to create a new file;
Enter the file name and press [EOB] to confirm and create a new program in current directory in the
memory, and load into the system by default;
Select [Close] to exit [Edit] interface;
In edit mode, enter the program content;
After editing all programs, press [Reset] to save the edited programs into the system memory.
8.1.2 PC serial port input
The step of transmitting files to controller through PC follows:
Set system baud rate and ID No.;
Connect to PC and run Adtech serial communication software;
Set the baud rate same as controller, and scan ID device;
Select the [Upload file to NC] button in the communication software;
Select CNC file in the popup dialog box and press [Open] button.
8.1.3 Copying processing files from USB disk
The step of copying CNC processing file to system memory through USB disk follows:
In the main menu, press [Edit] to enter program edit interface;
Select [File] to enter file operation interface;
Select USB disk and press [EOB] to enter;
Move the cursor to select a CNC file and then select [Copy];
Return to the root directory, locate the PROG directory in disk D, enter the directory, and select [Paste] to
complete copying.
8.2 Reading programs into work area
8.2.1 Reading programs from controller into work area
The step of loading files from system memory into work area follows:
Press [File] to enter file operation interface;
Select desired program, which is in PROG directory in disk D by default, press [EOB] to enter
subdirectory, or press [Cancel] to exit;
Move cursor to select desired program, press [EOB] to confirm and load the program.
8.2.2 Reading programs from USB disk into work area
The step of loading files from USB disk into work area follows:
Insert the USB disk;
Press [File] to enter file operation interface;
Select USB disk, move cursor to select a file in the disk, and press [EOB] to load the file.
8.3 Editing & modifying programs
The program in CNC memory can be edited with NC keypad. In the main menu, press [Edit] to enter program edit interface
and edit the program in current work area (for loading program into work area, refer to 8.2). The edit mode similar to
