Adtech CNC Technology Co., Ltd. 9. Program saving & editing
- 40 -
¾ Process variables are to customize the names of 20 variables (#100~#999) according to CSV configuration table, so that
the variable names have visual meanings. In programs, the user customized variables are transferred with variable
number.
9.11 Current mode instruction info
Display the G code mode info of current system;
In [Monitor] interface, you can check the running code info of current system:
Motion instruction: G00, G01
Select plane: G17, G18, G19
Coordinate logic: G90, G91
Workpiece coordinate system: G54, G59, G591…G599
Radius compensation: G40, G41, G42
Length compensation: G43, G44, G49
Compound instruction retracting plane: G98, G99
Principal axis rotation: S
Tool No.: T
