Advanced MxPro5 5000 Series User Manual

Specifications:
Item
Specification Details
Part Number:
Mx-5100
Mx-5200
Mx-5400
Mx-5800
Enclosure
Steel IP30 RAL7035
Steel IP30 RAL7035
Steel IP30 RAL7035
Steel IP30 RAL7035
Dimensions H x W x D mm
345 x 345 x 85
(/M) 345 x 430 x 120
(/L) 475 x 450 x 120
(/D) 475 x 450 x 190
345 x 430 x 120
(/L) 475 x 450 x 120
(/D) 475 x 450 x 190
475 x 450 x 120
(/D) 475 x 450 x 190
(/E) 750 x 450 x 190
750 x 450 x 190
Weight (excluding
batteries)
6Kg
(/M) 8Kg
(/L) 10Kg
(/D) 12kg
8Kg
(/L) 10Kg
(/D) 12Kg
10Kg
(/D) 12Kg
(/E) 18kg
20Kg
19” Rack
Dimensions H x W x D mm
Module
MXM-510-16U (22Kg)
MXM-510-20U (25Kg)
(/R) 266 x 482 x 125
730 x 535 x 230
910 x 535 x 230
(/R) 266 x 482 x 125
730 x 535 x 230
910 x 535 x 230
(/R) 266 x 482 x 125
730 x 535 x 230
910 x 535 x 230
Temperature
-5°C to 40°C
-5°to 40°C
-5°C to 40°C
-5°C to 40°C
Humidity (RH)
95 % Max
95 % Max
95 % Max
95 % Max
Cable Entries (20mm
knockouts)
13x top / 8x top rear
(/M) 17x top / 11x top rear / 2
bottom
(/L) 19x top / 11x top rear / 2
bottom
(/D) 30x top / 11x top rear / 3
bottom
17x top / 11x top rear / 2
bottom
(/L) 19x top / 11x top rear / 2
bottom
(/D) 30x top / 11x top rear / 3
bottom
19x top / 11x top rear / 2
bottom
(/D) 30x top / 11x top rear / 3
bottom
(/E) 30x top / 6x top rear / 3
bottom plus 2x double
knockout rear
30x top / 6x top rear / 3 bottom
plus 2x double knockout rear
AC Supply
(ratings marked on label
inside panel – see section
2.1 for location)
200-240V +10%, -15%
47 –63 Hz AC
1.0A max
200-240V, +10%, -15%
47 –63 Hz AC
1.4A max
200-240V, +10%, -15%
47 –63 Hz AC
1.4A max
200-240V, +10%, -15%
47 –63 Hz AC
2.8A max
Battery Capacity
24V 4Ah Internal (min)
24V 7Ah Internal (max)
(/M) 24V 12Ah Internal (max)
(/L) 24V 18Ah Internal (max)
(/D) 24V 24Ah Internal (max)
24V 4Ah Internal (min)
24V 12Ah Internal (max)
(/L) 24V 18Ah Internal (max)
(/D) 24V 45Ah Internal (max)
24V 4Ah Internal (min)
24V 18Ah Internal (max)
(/D) 24V 45Ah Internal (max)
(/E) 24V 45Ah Internal (max)
2x 24V 4Ah Internal (min)
2x 24V 18Ah Internal (max)
OR
1x 24V 45Ah Internal (max) /
1x 24V 45Ah External (max)
Charging Current
1.0A Temp Compensated
2.0A Temp Compensated
2.0A Temp Compensated
2x 2.0A Temp Compensated
Power Supply
On-board 24V DC, 3A High
Efficiency Off-Line Switched
Mode
On-board 24V DC, 5A High
Efficiency Off-Line Switched
Mode
On-board 24V DC, 5A High
Efficiency Off-Line Switched
Mode
2x On-board 24V DC, 5A High
Efficiency Off-Line Switched
Mode
Output Voltage
1
18.0V – 28.0V
18.0V – 28.0V
18.0V – 28.0V
18.0V – 28.0V
Ripple (Vpkpk)
1.0V
1.0V
1.0V
1.0V
Max Battery Ohms
1.6Ω ± 0.1 Ω
0.8Ω ± 0.1 Ω
0.8Ω ± 0.1 Ω
0.8Ω ± 0.1 Ω
Imax(a)/
Imax(b)
2
1.6A
3.0A
2.6A
5.0A
2.6A
5.0A
2.6A
5.0A (per chassis)
Number of Fire Zones
200 max
(2000 when networked)
200 max, across 2 loops
(2000 when networked)
200 max, across 4 loops
(2000 when Networked)
400 max, across 8 loops (2x 4
loops) (2000 when Networked)
Number of Loops
1
1-2
1 to 4
2 to 8 (2x 1 to 4)
Loop Current
3
500mA max.
500mA max. per Loop
500mA max. per Loop
500mA max. per Loop
Devices per Loop
Apollo 126 detector/call points per loop (max)
Hochiki 127 detector/call points per loop (max)
AV 240 detector/call points per loop (max)
Nittan 254 detector/call points per loop (max)
V
d
S
2095
Clause 6.2.5
Not more than 128
devices per loop
V
d
S
2095
Not more than 512
devices per panel
or 12000m
2
Protocols
Apollo S90, XP95, Discovery, Explorer and Hochiki ESP or AV or Nittan Evolution
Sounder Outputs
3
2 x 1A Programmable
2 x 1A Programmable
4 x 1A Programmable
8 (2x4) x 1A Programmable
Relay Outputs
(Programmable)
2 x1A 30VAC/DC (max)
10mA 5V (min)
2 x 1A 30V AC/DC (max)
10mA. 5V (min)
2 x 1A 30V AC/DC (max)
10mA. 5V (min)
4 (2x2) x 1A 30V AC/DC (max)
10mA. 5V (min)
Auxiliary Output
3 4
24V DC, 500mA
24V DC, 500mA
24V DC, 500mA
2x 24V DC, 500mA
Display
LCD White backlit 240 x 64 Graphical LCD
Programmable Inputs
8x Switch inputs, 1 x Hard wired input and Four x programmable push buttons c/w slide in labels
USB/RS232
USB B type interface and RS232 for PC connection
Network
Optional
Optional
Optional
ST4/STD – MXP-503
ST7/FT – MXP-509
Event Log
5000 Event & Diagnostic + 500 Fire
As our policy is one of constant product improvement the right is therefore reserved to modify product specifications without prior notice
1
Minimum/maximum specifications for the AUX, and Sounder outputs. Detector Loop voltage is not dependant on AC or battery voltage.
2
Only applicable if the panel is configured to turn off the charger in alarm. Otherwise, Imax(b)=Imax(a).
3
Total output current from panel not to exceed Imax(b) less internal power consumption.
4
Aux supply tracks a maximum of 0.5V below battery terminal voltage when no mains supply is available.
