4-162 ADAM 4000 Series User's Manual
Command Set
4050, 4052, 4053, 4060, 4051, 4055, 4068
Baud Rate
Code (Hex)
Baud Rate
03 1200 bps
04 2400 bps
05 4800 bps
06 9600 bps
07 19.2 Kbps
08 38.4 Kbps
76543210
not used
(000)
Module Identification
000 is ADAM-4050
001 is ADAM-4060
010 is ADAM-4052
011 is ADAM-4053
Figure 4-4
Checksum & Identification Parameter
$AA2
Example command: $452 (cr)
response: !45400600 (cr)
The command asks the digital I/O module at address 45h to
send its configuration data.
The digital I/O module at address 45h responds with baud rate
9600, no checksum function and the module is identifies as
ADAM-4050
not used (0)
Checksum status
0: Disabled
1: Enabled
Table 4-6
Baudrate Codes
To Next Page
