4-168 ADAM 4000 Series User's Manual
Command Set
4080, 4080D
Figure 4-5
Data format for 8-bit parameter
Not used
Frequency Gate Time
0: 0.1 seconds
1: 1.0 seconds
7 6 5 4 3 2 1 0
%AANNTTCCFF
Name: Configuration
Description: Sets the address, input mode, baud rate, checksum status and/
or frequency gate time for a specified counter/frequency
module
Syntax: %AANNTTCCFF (cr)
% is a delimiter character.
AA (range 00-FF) represents the 2-character hexadecimal
address of counter module that you want to interrogate.
NN represents the new hexadecimal address of the counter/
frequency module. Range is from 00h to FFh.
TT represents the input mode:
50h : counter input mode
51h : frequency measurement mode
CC represents the baud rate code (See table 4-7).
FF is a hexadecimal number that equals the 8-bit parameter
representing the checksum status and frequency gate time. The
layout of the 8-bit parameter is shown in figure 4-5.
Bits 0, 1, 3, 4, 5 and 7 are not used and set to 0.
(cr) is the terminating character, carriage return (0Dh)
Not used
Checksum status
0: Disabled
1: Enabled
Not used
