97
AIMB-581 User Manual
Appendix B
I/O Pin
Assignments
B.16
GPIO Pin Header (GPIO1)
B.17
L
VDS Connector: L
VDS1
T
able B.16: GPIO Pi
n Header (GPIO1)
Pin
Signal
Pin
Signal
1
GPIO0
2
GPIO4
3
GPIO1
4
GPIO5
5
GPIO2
6
GPIO6
7
GPIO3
8
GPIO7
9
+5V
10
GND
T
able B.17: L
VDS1 Connector
Pin
Signal
Pin
Signal
1
VDDSAFE_1
2
VDDSAFE_2
3
GND_1
4
GND_7
5
VDDSAFE_3
6
VDDSAFE_4
7O
D
0
-
8
E
D
0
-
9O
D
0
+
1
0
E
D
0
+
1
1
GND_2
12
GND_8
13
OD1-
14
ED1-
15
OD1+
16
ED1+
