ix AIMB-581 User Manual
5.2 Introduction ............................................................................................. 70
5.3 Windows XP/Windows 7 Driver Setup ....................................................71
Chapter 6 VGA Setup..........................................73
6.1 Introduction ............................................................................................. 74
6.2 Windows 7/XP......................................................................................... 74
Chapter 7 LAN Configuration.............................77
7.1 Introduction ............................................................................................. 78
7.2 Features................................................................................................ 78
7.3 Installation........................................................................................ .. 78
7.4 Windows® 7/XP Driver Setup (Intel 82579LM/82583V)................... ... 79
Appendix A Programming the Watchdog Timer..81
A.1 Programming the Watchdog Timer ......................................................... 82
A.1.1 Watchdog Timer Overview..................... .. ........................... 82
A.1.2 Programming the Watchdog Timer.... .... ... ............................ 82
Table A.1: Watchdog Timer Regist rs....................................... 84
A.1.3 Example Program ..................... .... .................................... 85
Appendix B I/O Pin Assignments..........................89
B.1 USB Header (USB56, USB78,USB9010,USB1112)............................... 90
Table B.1: USB Header (USB56)............................................... 90
B.2 VGA Connector (VGA ) .. .................................................................... 90
Table B.2: VGA Connector (VGA1) ........................................... 90
B.3 DVI1:DVI connec or . ............................................................................ 91
Table B.3: DVI1:DVI connector.................................................. 91
B.4 SPI_CN1: SPI F esh Card Pin Connector............................................... 91
Table B.4: SPI_CN1:SPI Fresh Card Pin Connector................. 91
B.5 PS/2 K yb ard and Mouse Connector (KBMS1).................................... 92
T ble B.5: PS/2 Keyboard and Mouse Connector (KBMS1) ..... 92
B.6 R 232 Interface (COM3/4/5/6) .............................................................. 92
Table B.6: RS-232 Interface (COM4~COM6) ............................ 93
B.7 CPU Fan Power Connector (CPU_FAN1) .............................................. 93
Table B.7: CPU Fan Power Connector (CPU_FAN1)................ 93
B.8 System Fan Power Connector (SYS_FAN1/2/3/4) ................................. 94
Table B.8: System Fan Power Connector (SYSFAN1/SYSFAN2/
SYSFAN3/SYSFAN4)............................................... 94
B.9 Power LED & Keyboard Lock Connector (JFP2) .................................... 94
Table B.9: Power LED & Keyboard Lock Connector (JFP2)...... 94
B.10 Power switch/HDD LED/SMBus/Speaker (JFP1) ................................... 95
Table B.10:Power Switch/HDD LED/SMBus/Speaker (JFP1) .... 95
B.11 USB/LAN ports (LAN1_USB12/LAN2_USB34)....................................... 95
Table B.11:USB Port................................................................... 95
Table B.12:Ethernet 10/100 Mbps RJ-45 Port............................ 95
B.12 Line In, Line Out, Mic In Connector (AUDIO1)........................................ 96
B.13 Serial ATA0/1 (SATA1 ~ 6) ..................................................................... 96
Table B.13:Serial ATA 0/1 (SATA1 ~ 6) ..................................... 96
B.14 AT/ATX Mode (PSON1).......................................................................... 96
Table B.14:AT/ATX Mode (PSON1) ........................................... 96
B.15 HD Audio Interface (FPAUD1) ................................................................ 96
Table B.15:AC-97 Audio Interface (FPAUD1)............................. 96
B.16 GPIO Pin Header (GPIO1)...................................................................... 97
